| Part Number | Panel Thickness | Std Pack Qty |
|---|---|---|
| TLJ-200-01 | 0.8-2 | 500 |
| TLJ-300-01 | 0.05-1.6 | 500 |
Related products
Pg Nylon Cable Gland
TECHNICAL DATA
Material : Nylon 6/6
OPERATING TEMP : -30°C to +100°C (+150°C – Short Term)
Thread : PG Standard Mounting Thread & Long Mounting Thread
Flammability : UL94 V-2, UL94 V0
Color : Black and Grey Other Colours on Request
Protection Rating : IP68
Approval : ROHS, UL, CE, REACH,
- Locknut and sealing washer available separately
Locknuts and Sealing Washers for Cable Glands
Technical Data
Material: Nylon 6/6 – Neoprene
OPERATING TEMP: -30°C to +100°C
Thread: PG & Metric
Flammability: UL94 V-2, UL94 V0
Color: Black and Grey Other Colours on Request
Approval:ROHS, UL, CE, REACH,
- Protection rating Ip68
Silicone Coated Fiberglass Sleeving
TECHNICAL DATA
Material : fiberglass Multi filament and silicone elastomer
Thermal class : “H” Class
Thermal temp :-60°C to +180°C (Peak +200°C)
Sizes : 0.50MM to 50mm
Break down volt : 1.5kv,4kv,7kv
Flammability : UL 1441 – VW–1 (UL Grade–A)
Expandability : 1:2 (As per Customer requirement)
Color : Natural & Black, Other Colors on request
Shelf life : More than 25 years
Approval : ROHS, UL, CE, REACH
Features :
|
Applications :
|
