| PROPERTY | SPECIFICATION REQUIREMENT | TEST METHOD | TYPICAL VALUE |
|---|---|---|---|
| Tensile strength (Room temp.) | Min. 10.4Mpa | UL224 | Pass |
| Elongation at break (Room temp.) | Min. 200% | UL224 | Pass |
| Tensile strength after aging | Min. 7.3Mpa | UL224 | Pass |
| Elongation after aging (158? 168hrs) | Min. 100% | UL224 | Pass |
| Voltage withstand (Un-aged) | Withstand 2.5kV for 1 minute and breakdown | UL224 | Pass |
| Voltage withstand (Aged) | Withstand at least half of un-aged breakdown voltage for 1 minute and breakdown | UL224 | Pass |
| Corrosion (158? 168hrs) | No corrosion | UL224 | No sign of deg. |
| Longitudinal shrinkage | ≤10% | UL224 | ≤5% |
| Low-temperature flexibility (-55? 4hrs) | No cracking | UL224 | Pass |
| Flammability | VW-1 | UL1581 | Pass |
| Volume resistivity | Min. 10 14Ω·m | UL224 | Pass |
| Heat shock | No cracking | ASTM D2671 | Pass |
| Dielectric strength | >13.8kV/mm | ASTM D2671 | >25kV/mm |
| PROPERTY | SIZE (mm) | AS SUPPLIED | AFTER RECOVERED | AFTER RECOVERED | SPQ-(M/ROLL) | MOQ-(M/ROLL) |
|---|---|---|---|---|---|---|
| ID (mm) | ID MAX (mm) | WALL THIKNESS NOM (mm) | ||||
| REHST(UT)-1.0 | Φ1.0 | 1.4±0.2 | 0.65 | 0.20 | 200 Mtr | 5000 Mtr |
| REHST(UT)-1.5 | Φ1.5 | 1.9±0.2 | 0.85 | 0.20 | 200 Mtr | 5000 Mtr |
| REHST(UT)-2.0 | Φ2.0 | 2.4±0.2 | 1.00 | 0.22 | 200 Mtr | 5000 Mtr |
| REHST(UT)-2.5 | Φ2.5 | 2.9±0.2 | 1.30 | 0.25 | 200 Mtr | 5000 Mtr |
| REHST(UT)-3.0 | Φ3.0 | 3.4±0.2 | 1.50 | 0.28 | 200 Mtr | 5000 Mtr |
| REHST(UT)-3.5 | Φ3.5 | 3.9±0.2 | 1.80 | 0.28 | 200 Mtr | 5000 Mtr |
| REHST(UT)-4.0 | Φ4.0 | 4.4±0.2 | 2.00 | 0.30 | 200 Mtr | 5000 Mtr |
| REHST(UT)-4.5 | Φ4.5 | 4.9±0.2 | 2.30 | 0.30 | 200 Mtr | 5000 Mtr |
| REHST(UT)-5.0 | Φ5.0 | 5.5±0.2 | 2.50 | 0.32 | 100 Mtr | 5000 Mtr |
| REHST(UT)-6.0 | Φ6.0 | 6.5±0.2 | 3.00 | 0.32 | 100 Mtr | 5000 Mtr |
| REHST(UT)-7.0 | Φ7.0 | 7.5±0.3 | 3.50 | 0.32 | 100 Mtr | 5000 Mtr |
| REHST(UT)-8.0 | Φ8.0 | 8.5±0.3 | 4.00 | 0.32 | 100 Mtr | 5000 Mtr |
| REHST(UT)-9.0 | Φ9.0 | 9.5±0.3 | 4.50 | 0.35 | 100 Mtr | 5000 Mtr |
| REHST(UT)-10.0 | Φ10.0 | 10.5±0.3 | 5.00 | 0.35 | 100 Mtr | 5000 Mtr |
| REHST(UT)-11.0 | Φ11.0 | 11.5±0.3 | 5.50 | 0.40 | 100 Mtr | 5000 Mtr |
| REHST(UT)-12.0 | Φ12.0 | 12.5±0.3 | 6.00 | 0.40 | 100 Mtr | 5000 Mtr |
| REHST(UT)-13.0 | Φ13.0 | 13.5±0.3 | 6.50 | 0.40 | 100 Mtr | 5000 Mtr |
| REHST(UT)-14.0 | Φ14.0 | 14.5±0.3 | 7.00 | 0.40 | 100 Mtr | 5000 Mtr |
| REHST(UT)-15.0 | Φ15.0 | 15.5±0.4 | 7.50 | 0.40 | 100 Mtr | 5000 Mtr |
| REHST(UT)-16.0 | Φ16.0 | 16.5±0.4 | 8.00 | 0.40 | 100 Mtr | 5000 Mtr |
| REHST(UT)-17.0 | Φ17.0 | 17.5±0.4 | 8.50 | 0.40 | 100 Mtr | 5000 Mtr |
| REHST(UT)-18.0 | Φ18.0 | 18.5±0.4 | 9.00 | 0.42 | 100 Mtr | 5000 Mtr |
| REHST(UT)-20.0 | Φ20.0 | 20.5±0.5 | 10.00 | 0.45 | 100 Mtr | 5000 Mtr |
| REHST(UT)-22.0 | Φ22.0 | 22.5±0.5 | 11.00 | 0.45 | 100 Mtr | 5000 Mtr |
| REHST(UT)-25.0 | Φ25.0 | 25.5±0.5 | 12.50 | 0.45 | 50 Mtr | 5000 Mtr |
