STANDARD Hdpe Spiral Guard

Technical Data

Material: HDPE (High-Density Polyethylene)
Operating Temp: -40°C To + 130 °C
Sizes: 12mm to 140mm
Flammability: Highly UV resistant
Color: Black, Other Colours on Request
Approval: ROHS, UV, CE, REACH,MSHA, FRAS
Roll Length: 20Mtr / 50Mtr

It provides good anti-crushing property and shows high resistance to abrasion and UV rays. It is flexible in structure and it is easy to fit and supports for risk of industrial injury as well be It can continue working at +90°C. We supply this material in conveniently rolled and packed. cartons which supports for easy storage also

Applications and Benefits of Spiral guard Suits:
  • Flexible for fixing and removing. Provides good protection and It is flexible for fixing and removing.
  • Provides good protection and prevents from injury risks
    in industries.
  • Heavy duty hose wrap & flexible and easy-to-install
  • Highly UV resistant, tolerate both frost and heat & Long lasting
    hose protection
  • We supply standard product in 20 & 50 meter rolls.
ENQUIRY!
DISCPRITION PART NUMBER INCHES (OD) OD(D)mm ID(d)mm WallThickness(mm) PITCH(mm) Recommended Range
(mm & inch)		 SPQ In mtr MOQ In mtr
HDPE Spiral Guard RESG12-50 1/2″ 12 9 1.5 10 9mm-13mm
0.35-0.51″		 50 500
HDPE Spiral Guard RESG16-50 2/3″ 16 12.6 1.7 12 13mm-18mm
0.51-0.71″		 50 500
HDPE Spiral Guard RESG20-50 3/4″ 20 16 2.0 16 16mm-22mm
0.63-0.87″		 50 500
HDPE Spiral Guard RESG25-50 1″ 25 20.6 2.2 20 20mm-27mm
0.78-1.06″		 50 500
HDPE Spiral Guard RESG32-50 1 1/4″ 32 27 2.5 22 27mm-36mm
1.06-1.42″		 50 500
HDPE Spiral Guard RESG40-50 1 3/5″ 40 34.6 2.7 27 34mm-44mm
1.34-1.73″		 50 500
HDPE Spiral Guard RESG50-20 2″ 50 44 3.0 30 43mm-55mm
1.69-2.16″		 20 200
HDPE Spiral Guard RESG63-20 2 1/2″ 63 55.4 3.8 37 55mm-67mm
2.16-2.64″		 20 200
HDPE Spiral Guard RESG75-20 3″ 75 66 4.5 42 66mm-80mm
2.60-3.15″		 20 200
HDPE Spiral Guard RESG90-20 3 1/2″ 90 80 5.0 45 80mm-98mm
3.15-3.86″		 20 200
HDPE Spiral Guard RESG110-12 4 1/3″ 110 99 5.5 50 99mm – 115mm
3.90-4.53″		 12 120
HDPE Spiral Guard RESG125-12 4 9/10″ 125 113 6.0 55 113mm-130mm
4.45-5.12″		 12 120
HDPE Spiral Guard RESG140-09 5 1/2″ 140 128 6.0 55 125mm-145mz
4.92-5.70″		 9 90
